Bowflex BXE116 - Hardware and Tools; Included and Recommended Tools

Assembly / Owner’s Manual
9
Hardware / Tools
Tools
Included Not Included
6mm - short
6mm - long
(recommended)
#2
13mm
15mm
19mm
+DUGZDUH
Item Qty Description Item Qty Description
$ 29 %XWWRQ+HDG6FUHZ0[[ G 6 Pan Phillips Screw M3.9x16
% 31 Lock Washer, M8 H 8 Flat Washer, M8x24 Large
C 18 Flat Washer, M8x18 I 6 Wave Washer, M8
D 2 Lock Nut, M8 J 9 Curved Washer, M8
( 2 %XWWRQ+HDG6FUHZ0[[ K 2 Socket Head Cap Screw, M8x16
F 4 Pan Phillips Screw M3.9x38 L 2 Pivot Pin
Note:6HOHFWSLHFHVRI+DUGZDUHKDYHEHHQSURYLGHGDVVSDUHVRQWKH+DUGZDUH&DUG%HDZDUHWKDWWKHUHPD\EHUHPDLQLQJ+DUGZDUH
after the proper assembly of your machine.
AB C D E F
GH
I
J
KL
