Bowflex Max Trainer M8 - Parts and Hardware Identification

Assembly / Owner’s Manual
7
A decal has been applied to all right (“ R ”) and left (“ L ”) parts to assist with assembly.
Item Qty Description Item Qty Description
7 1 Console Assembly (w/Aerobars) 14 1 Rail Assembly
8 1 Dynamic Handlebar, Left 15 1 Stabilizer Assembly
9 2 Leg 16 4 Leveler
10 2 Pedal 17 2 Cap
11 1 Stabilizer Shroud, Left 18 1 AC Adapter
12 1 Stabilizer Shroud, Right 19 1 Manual Kit
13 1 Dynamic Handlebar, Right 20 1 Media Capture Bar
( 2 Boxes )
Box 1
Item Qty Description
1 1 Frame
2 1 Shroud, Rear
3 2 Foot Pad Insert, Front
4 2 Foot Pad Insert
5 2 Foot Pad
6 1 Hardware Card
