Bowflex TREADCLIMBER 5000

Other manuals for Bowflex TREADCLIMBER 5000

Assembly Manual32 pages

Questions and Answers

A
Angel TaylorAug 14, 2025
How to troubleshoot Bowflex Fitness Equipment that will not power up?
- K
  Kenneth HillAug 14, 2025
  If your Bowflex Fitness Equipment won't power up, first, ensure the outlet is working by testing it with another device. Check that the power cord is securely connected to both the unit and a non-GFI wall socket. Make sure the power switch at the rear of the unit is in the “ON” position, and the safety key is properly inserted into the console. If these steps don't work, remove the rear plastic covers and contact customer service for further assistance.
R
Regina MitchellAug 21, 2025
What to do if Bowflex TREADCLIMBER 5000 displays 'err LS' or 'err OS'?
- K
  Keith CisnerosAug 21, 2025
  If your Bowflex Fitness Equipment belts stop turning and displays “err LS” or “err OS”, recalibrate the machine. If the issue persists, cycle the power, put the machine in calibration mode, and remove the right rear plastic cover to view the LED diagnostics. Check if LED D is blinking when you manually advance the treadle. If not, ensure the speed sensor wire is connected to the motor controller board at “P1”, check the connection of the speed sensor to the jumper wire, and adjust the speed sensor (using a business card to set the gap). If LED D still doesn't flash, replace the sensor. If LED D is flashing, check the I/O cables for damage and continuity. If you don't have a multi-meter, contact customer service for replacement cables and assistance.
M
Morgan MaloneAug 25, 2025
Why is the speed displayed not accurate on my Bowflex TREADCLIMBER 5000 Fitness Equipment?
- D
  Debbie ZimmermanAug 25, 2025
  If the speed displayed on your Bowflex Fitness Equipment is inaccurate, the display might be set to the wrong unit of measure (English/Metric). You can change the display units. Also, the machine may be out of calibration, so recalibrate it.
J
Jordan QuinnAug 27, 2025
Why is my Bowflex Fitness Equipment making knocking noises?
- L
  Laura TaylorAug 28, 2025
  If your Bowflex Fitness Equipment is making knocking noises in TreadClimber or stepper mode, but not in treadmill mode, first check the treadle alignment. Make sure the treadles are centered and not contacting the uprights. If they aren't centered, slightly loosen the rear baseplate bolts, center the treadles, and then securely tighten the outer and inner bolts. Also, unplug the unit, wait 5 minutes, and remove the left side plastic drive cover. Tighten the bolt attaching the drive pulley to the drive shaft and the setscrew on the flywheel motor pulley. Reinstall the cover. Inspect the igus bushings for cracks and replace if necessary. Finally, check and tighten the upper and lower bolts connecting the hydraulic cylinders to the unit.
M
Michelle HinesAug 30, 2025
Why is heart rate not displayed on my Bowflex TREADCLIMBER 5000 with chest strap?
- D
  dayjulianAug 31, 2025
  If the heart rate is not displayed while using a chest strap with your Bowflex Fitness Equipment, try moistening the skin contact area on the chest strap. Also, turn off any nearby televisions, AM radios, microwaves, or computers. Test the chest strap with another heart rate monitoring device. If it still doesn't emit a signal, replace the chest strap transmitter. If the chest strap works with other devices, and there are no interference sources, replace the HR receiver.
V
Valerie SmithSep 3, 2025
Why is my Bowflex Fitness Equipment making a grinding noise?
- M
  Michael LawsonSep 3, 2025
  If your Bowflex Fitness Equipment is making a speed-dependent grinding or scraping noise, check the walking belt alignment. Contact between the belt and metal guides can cause this sound. If misaligned, follow the belt alignment procedure. If the issue persists, contact customer service for assistance regarding the rollers or motor.
J
Julie NielsenSep 6, 2025
Why is the floors climbed display not updating on my Bowflex TREADCLIMBER 5000?
- J
  Jennifer MedinaSep 6, 2025
  If your Bowflex Fitness Equipment's floors climbed display isn't updating, ensure the pedals pass each other completely so the magnet on the treadle passes the step sensor. Make sure the treadles are not locked in treadmill mode and move enough to register a step. Also, check that the step sensor wire is connected at the rear of the machine.
S
Steven WrightSep 9, 2025
Why is my Bowflex TREADCLIMBER 5000 Fitness Equipment making a ticking sound?
- T
  Theresa CuevasSep 10, 2025
  If your Bowflex Fitness Equipment is making a “tick” sound or scraping noise from under the treadle, the belt seam may be contacting the metal belt guide. Adjust the belt slightly to alleviate the noise.
F
Francisco KennedyNov 16, 2025
What to do if Bowflex Fitness Equipment belt is slipping?
- D
  Dorothy AdamsNov 17, 2025
  If you experience hesitation or belt slipping when walking on your Bowflex Fitness Equipment, it could be due to belt tension. To check, set the speed to 2 MPH, step on one treadle, and try to stop it. If one belt stops but the roller and other belt continue, adjust the walking belt tension. If both belts stop but the motor is still turning, adjust the drive belt tension. To adjust the walking belt tension, tighten the adjustment bolts at the front of the unit in full turn increments, ensuring both bolts on each roller are adjusted equally. Restart the unit after each adjustment to check for improvement. If slipping persists, refer to the drive belt checklist. To adjust the drive belt, unplug the unit and wait 5 minutes. Turn the unit on its side and check that the shipping bolt has been...

Summary

Bowflex TreadClimber Owners Manual

Preface

Product Features

Product Specifications

Important Safety Warnings

Emergency Stop Procedures

Instructions on how to safely stop the machine in an emergency.

Care of the Machine

Helpful Hints, Initial Service, and Cleaning

Advice for assembly, initial use, and regular cleaning of the equipment.

Walking Belt and Deck Lubrication

Procedure for lubricating the walking belt and deck for smooth operation.

Inspecting, Hours Used, and Storage

Steps for inspecting the machine, tracking usage, and proper storage.

Getting Started

Before You Start

Prerequisites and checks before operating the TreadClimber for the first time.

Select Your Workout Level

Guide for choosing and adjusting workout resistance levels based on fitness.

Adjusting Workout Level Settings

Detailed instructions on how to change the resistance settings on the hydraulic cylinders.

Pausing or Stopping

Procedures for safely pausing or stopping the treadmill and console.

TC 5000 Displays and Quick Start

Explanation of console displays and how to use the Quick Start function.

Remote Heart Module and Chest Strap Usage

How to set up and use the heart rate monitor for workouts.

Information About Heart Rate Calculations

Understanding target heart rate zones for fat burning and fitness.

TC3000;TC1000 Features and Displays

Overview of console features and display information for specific models.

Setting English or Metric Measurement Units

Instructions for configuring the console to display units in English or Metric.

Walking Belt Adjustment and Tension

Guide for adjusting belt tracking and ensuring proper belt tension.

Workout Instructions

Determining Your Fitness Level

Tests and scales to assess your current fitness level for program selection.

Locking the Treadles for Treadmill Workout

Procedure to lock the treadles for conversion to treadmill mode.

Starting a Treadmill Workout

Step-by-step guide to begin a workout in treadmill mode.

Starting a Stair-Stepper Workout

Instructions for initiating a workout in stair-stepper mode.

Bowflex TreadClimber Workout Mode

How to perform workouts specifically in the TreadClimber mode for maximum benefit.

Preliminary TreadClimber Workout Plan

Recommended initial 4-week workout regimen for new users.

Repairs and Maintenance

Ordering Replacement Parts

How to order replacement components for the TreadClimber.

Routine Maintenance and Diagnostics

General upkeep, cleaning, and accessing diagnostic LED boards.

Verify Speed Sensor (TC1000)

Test procedure to ensure the speed sensor is functioning correctly on TC1000.

Calibration Procedures and Troubleshooting

Steps for calibrating the machine and resolving common calibration errors.

Parts Identification

Bowflex TreadClimber Satisfaction Guarantee

Unauthorized Returns Policy

Conditions and consequences for returning merchandise without proper authorization.

Important Contact Numbers
