BOXER RU-DP01 - Adjustable Torque Clutch; Adjusting Torque Settings; Maintenance

This tool has been designed for trouble-free service and requires very little user
maintenance. Keep the tool clean and free from dust/dirt build-up. Do not use
solventswhencleaningplasticparts.Plasticissusceptibletodamagefrom
various types of commercial solvents and may be damaged by the use of
solvents. Use a clean, damp cloth to remove dirt, dust, and debris.
Keep your tool in good condition by adopting a regular maintenance program.
Beforeuse,examinethegeneralconditionofyourtool.Inspectswitchesand
power cord for damage. Check for loose screws, misalignment, binding of
moving parts, improper mounting, broken parts, and any other condition that
mayaffectthesafeoperationofthetool.Ifanabnormalnoiseorvibrationoc-
curs, turn the tool OFF immediately and have the problem corrected before
further use. Do not use a damaged tool.
Neverdisassemblethetoolortrytodoanyrewiringonthetool’selectrical
system. Clean dust and debris from vents. Keep the tool handles clean, dry, and
free from oil or grease. Use only mild soap and a damp cloth to clean your tool
since certain cleaning agents and solvents are harmful to plastics and other insu-
lated parts. Some of these harmful solvents include: gasoline, turpentine, lacquer
thinner, paint thinner,
Maintenance
ADJUSTABLE TORQUE CLUTCH
This drill is equipped with an adjustable torque clutch ofr driving different types of
screws into different materials. The proper setting depends on the type of mate-
rialandthesizeofscrewyouareusing.
TO ADJUST TORQUE
Identifythe23torqueindicatorsettingslocatedonthefrontofthedrill.(Fig.10)
Rotate adjusting ring (2) to the desired setting.
1-5 For driving small screws
6-10 For driving screws into soft material
11-15 For driving screws into soft and hard materials
16-20 For driving screws in hard wood
21-23 For heavy drilling
