Boyd S2614 - Installation Instructions; Chair Installation; Initialization Procedure

11
SCHM-002
Rev 2
Locaon: Full size templates are available upon request for laying out location of chair and utilities (if required) prior to actual
installation.
Cauon: Base must be anchored to floor. Failure to do so may result in serious bodily injury to operator and/or patient and
could cause unwarranted product damage. Chairs not properly anchored do not meet warranty requirements.
1. Posion chair as desired. Drill holes in oor through base plate
mounng holes. Anchor base to oor with four (4) anchors
provided.
Cauon: To prevent possible injury or damage, do not drill through
carpeting. Cut away carpeting at anchor hole locations.
2. Make ulity connecons in oor in front of base (if required).
3. Ensure safety covers are in place and removable upholstery is
secure. Shiing may have occurred during handling or shipping.
4. Plug chair into approved A/C outlet. Refer to Serial Number Scker
for required voltage.
5. Turn main power switch ON (C1) located on the electrical panel at
the back of base.
6. Perform initialization procedure. (see below)
7. Perform safety and operaonal check.
8. If chair does not operate correctly, see the “Troubleshoong”
secon of this manual.
9. When chair is operang correctly, turn main power OFF (C1) unl
chair is to be used.
10. Refer to “Upholstery removal and installation” for upholstery use.
Inializaon Procedure
1. Run the back motor to its full down position.
2. Run the base motor to its full up position.
3. Run the tilt motor to its full tilt position.
4. Run the toe motor (S2614 only) to its full up position.
5. Press and release HOME button and allow both motors to fully return to the patient exit position (back full up, base full
down, tilt up and toe down (S2614 only)).
Chair is now initialized and ready for use.
Installaon Instrucons
Chair Installation
Model: S2614 & S2615
Back View
of Chair
Main Power
Switch (C1)
Serial Number
Scker
Light Power
Switch (C2)
Anchors
4 places
Foot Control
Connecon
Front View
of Chair
Hand Control
Connecon
A/C Input
to Chair
Home
Base Up
Hand
Control
Back Down
Tilt Back
Toe Up
(S-2614)
Foot Control
S2614/S2615
Back Down
S2614
Home
S2615
Tilt Up
Base Up
Toe Up
Tilt Up
Back Down
Base Up
Home
