Boyd S2614 - Operation Instructions; Programming Instructions; General Operating Instructions

12
SCHM-002
Rev 2
Model: S2614 & S2615 Chairs
Programming Instructions:
1. Read these instrucons completely before you begin programming.
2. Using the motor controls, posion the chair as desired.
3. Wait at least three (3) seconds and push and hold the save (S) buon for
four (4) seconds. The system will issue a confirmation beep. Within two
(2) addional seconds, push the buon of the desired posion (i.e.
“1”,”2”,”3”). The system will issue a second confirmation beep. This will
automacally replace any pre-programmed posion.
4. Reposion chair and recall that posion to insure that it has been
programmed correctly.
5. Repeat steps 2, 3, and 4 unl all desired posions are programmed. You
can save up to three (3) posions.
6. HOME is a preset posion that cannot be changed.
The programmed posions can be aained at any me and from any posion.
General Operating Instructions:
1. Before operang chair, watch for any obstrucons under chair.
 Do not allow small children to play on, around, or underneath
chair or base.
 Do not allow service animals on or underneath chair or base.
 Any obstrucon that may hinder normal movement of any part of
the chair should be cleared away before inializing any
posioning of the chair.
 Check to be certain that all people are clear of the chair before
operang chair funcons.
2. Chair should be turned OFF at main power switch (C1) any me it is not
being used.
Operang Instrucons
Outlet for use with Boyd Light Accessory
Only and may not be repositioned.
Improper use could lead to injury or
equipment damage.
Foot Control
S2614/S2615
Save
Posion 2
Posion 3
Position 1
S2615
S2614
Save
Posion 3
Position 1
Posion 2
Switched
Outlet
Active
Outlet
230V
Outlet
115V
Outlet
