Via | Foldable power wheelchair Foldable power wheelchair | Via
5. Technical data
Dimensions and weights
Maximal payload
Max. User weight:
Seat width:
max. effective seat width:
Seat depth:
Height of seat cushion:
Seat angle:
Seat height, from floor:
Gap between armrest and seat surface:
Backrest height:
Backrest height:
Total length:
Total width:
Transport length/height dimensions:
Kerb weight:
Components’ weights:
Electronics
Batteries:
Charger:
Motor:
Controller:
Tyres
Castors:
Drive wheels:
161 kg (incl. loading the bag
with max. 5kg)
120 kg
430 mm
490 mm
430 mm
50 mm
5°
520 mm to front seat edge
(without seat cushion)
275 mm (without seat
cushion)
560 mm (without seat
cushion)
14°
1090 mm
690 mm (with control unit)
870 mm / 460 mm
36 kg
32 kg, incl. batteries
24V/20Ah lithium ion
480 Wh
2.5A
180 W (Class F S2, 10 min)
4200 RPM
PG VSI 50A
PU 8“
12,5“ pneumatic tyres
2.7 bar
Drive characteristics
max. speed (forwards):
Safe nominal slope:
Max. Obstacle height:
Range:
Turning circle:
Braking distance (from max.
speed)*:
Static stability:
Operating forces
Joystick:
Keys on the control unit:
Disconnecting the drives:
Operating conditions
Temperature:
Humidity:
Storage conditions
Temperature:
Humidity:
Material
Frame:
Seat and backrest:
Features
• Seat cushion
• Crutch holder
• Anti-tip wheels
*Please note that the braking distance may increase on uneven, steep ground.
The product dimensions stated are below the manufacturing tolerances of +/- 10 mm
6 kph
3°
40 mm
approx. 15 km
1720 mm
500 mm
17° uphill
21° downhill
20° sidewards
< 13.5 N
< 5 N
< 60 N
-25 - +50°C
20 - 80%
-40 - +65°C
45 - 60%
Aluminium
Nylon
