B+S TF Series - Page 6

TF and RF Series B&S Commercial Kitchens
6
Please note that the minimum gas inlet pressure should be at least 1.13KPa (Natural Gas) and 2.75KPa
(Propane). Gas pressure must be checked when all other equipment on the same line is turned ON high.
TF 451s is the 450 wide split tank fryer (can be Verro , Black or Kplus) (single pan split into two). It is 39
MJ/h (NG) and 38 MJ/h (LPG) per pan. When both the burner system in both section of the pan is used, total
consumption would be 76MJ/h (NG) and 78MJ/h (LPG)
The rapid fryer unit (RF) is available with 1,2,3 and 4 pans according to the customer requirements
TABLE 2: STANDARD MODEL GENERAL INFORMATION
Weight
(kg)
Overall Height
(mm)
Overall Depth*
(mm)
Overall Width*
(mm)
RF-400
100
1130
800
400
TF-451
100
1,130
800
450
TF-452
200
1,130
800
900
TF-453
300
1,130
800
1,350
TF-454
400
1,130
800
1,800
TF-601
120
1,130
800
600
TF-602
240
1,130
800
1,200
TF-603
360
1,130
800
1,800
TF-604
480
1,130
800
2,400
Unit
Length(mm)
Depth(mm)
Height(mm)
RF-1
625
970
1300
RF-2
1250
970
1300
RF-3
1875
970
1300
RF-4
2500
970
1300
*Denotes minimum all dimensions +/- 5mm tolerance
For Verro Units Overall height would be 1030mm
Overall Dimensions – Custom made appliances
Height overall splash back 1030mm - 1,130mm( including adjustable legs)
Width 1,800mm minimum with 4 pans (450mm wide pans)
2400mm minimum with 4 pans (600mm wide pan)
Depth 800mm minimum
