UNPACKING AND SETUP OF THE MACHINE
1- Remove the packing and make sure of the machine integrity.
2- Before using the machine proceed in this way:
2.1 Take from the Waste Hopper Table B-1
the Side Broom – Table A-20
2.2 Unscrew the screw and washers Table A-24 from the Gearmotor Table A-15.
Insert the broom on the gearmotor axle having the key slot matching the key,
leaving the spacer between the broom and the gearmotor, then fix it with the
screw and washers
2.3 Remove the Cover Table A- 1 unscrewing the four screws that keep it fixed on the
machine frame.
2.4 Make sure that the input voltage of the Battery-charger corresponds to the input
voltage available.
The machine leaves the factory set for an input voltage of 120 VAC
For input voltages of 210/240 VAC :
Follow connections as per Table B – 5
2.5 Connect the battery terminals paying attention to the correspondence of polarities.
2.6 Provide for the charge of the battery (See the following directions PAGE 4 –
Battery-charger).
MACHINE SETUP
State of rest: the machine can be placed whether with the handle folded down or with the
handle in vertical position.
