MACHINE STARTING UP AND OPERATION
Main broom
Operating the switch (Figure 1-2) the main broom Table C- 14 starts to work reaching
immediately the running speed. The lighting of a green LED signals the regular operation.
With the main broom working it is possible to operate:
Side broom
Operating the switch (Figure 1-3) the side broom will start working.
To adjust the side broom operate on the knob (Table A- 22).
Vacuum
Operating the switch (Figure 1-4) the centrifugal electric motor fan starts to work.
Electric filter-shaker
With the battery connected, the electric filter-shaker is always active.
- The operation takes place pressing the push-button (Figure 1- 1).
- With the machine in movement, before operating the filter-shaker, it is suggested to
switch-off the vacuum, switch (Figure 1- 4).
- With the machine still and the hopper out, switch-off the suction and the main broom
switch (Figure 1 - 2) , before operating the filter-shaker.
Battery
- The “discharged battery” limit is signalled by the lighting of a red Led and afterwards
by the motors switching off.
- To complete the work switch-off for a while the switch (Figure 1- 2).
- To make use of a further residual of charge, switch-off the side broom switch
(Figure 1- 3).
CAUTION: In case of prolonged inactivity of the machine disconnect the battery
terminals.
Battery charger
To charge the battery:
- Make sure that the transformer connections have been set for the suitable voltage
from 90 up to 240 volts Figure 3 – Page 9.
- Use the cable already connected to the machine (Table A- 11), insert the plug in any
suitable AC. outlet.
- The time required for the complete recharge varies from 8 to 15 hours, depending on the
power grid condition.
- During the charge all functions are automatically switched-off.
CAUTION: during the battery charging avoid to have contacts with parts of the circuit
concerned by the network voltage.
