4 TECHNICAL DATA
16
4.1 Chassis tightening torques
Brake fluid reservoir for front brake
cover
‑ 1 Nm (0.7 lbf ft)
Brake fluid reservoir for rear brake
cover
‑ 3.5 Nm (2.58 lbf ft)
Remaining screws, chassis EJOT PT
®
K50x12 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOT PT
®
K50x14 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOT PT
®
K50x16 2 Nm (1.5 lbf ft)
Remaining screws, chassis EJOT PT
®
K50x18 2 Nm (1.5 lbf ft)
Remaining screws, chassis EJOT PT
®
K45x12 1 Nm (0.7 lbf ft)
Screw, air filter box cover EJOT PT
®
K60x30 2.5 Nm (1.84 lbf ft)
Screw, ball head holder on head-
light
EJOT ALtracs
®
50x12 7 Nm (5.2 lbf ft)
Screw, brake assembly 5 Nm (3.7 lbf ft)
Screw, exhaust valve cover fasten-
ing
EJOT SF
®
M4x6‑K 4 Nm (3 lbf ft)
Screw, intake air temperature sen-
sor
EJOT PT
®
K50x16 2 Nm (1.5 lbf ft)
Screw, radiator fan cover EJOT DELTA PT
®
40x46/10 1 Nm (0.7 lbf ft)
Screw, SAS on air filter box EJOT PT
®
K50x16 2 Nm (1.5 lbf ft)
Screw on handle M4 6 Nm (4.4 lbf ft)
Screw, fixed grip, left M4 3 Nm (2.2 lbf ft)
Screw, side stand sensor M4 2 Nm (1.5 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw for throttle grip M5 3.5 Nm (2.58 lbf ft)
Screw, 6D sensor holder M5 2.7 Nm (1.99 lbf ft)
Loctite
®
243™
screw, absorbing element, combi-
nation instrument
M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Screw, cable channel M5 5 Nm (3.7 lbf ft)
Screw, chain sliding guard M5 5 Nm (3.7 lbf ft)
Screw, combination instrument M5 1 Nm (0.7 lbf ft)
Screw, combination switch, left M5 5 Nm (3.7 lbf ft)
Screw, combination switch, right M5 5 Nm (3.7 lbf ft)
Screw, front turn signal bracket M5 3.5 Nm (2.58 lbf ft)
Screw, fuel level sensor M5 3 Nm (2.2 lbf ft)
Screw, fuel tank filler cap M5 3 Nm (2.2 lbf ft)
Screw, fuel tank spoiler M5 2.5 Nm (1.84 lbf ft)
Screw, fuse box support M5 6 Nm (4.4 lbf ft)
Screw, headlight locking cap M5 3.5 Nm (2.58 lbf ft)
Screw, heat protector on main
silencer
M5 4 Nm (3 lbf ft)
Screw, injection valve M5 4 Nm (3 lbf ft)
Loctite
®
243™
Screw, intake trumpet M5 6 Nm (4.4 lbf ft)
