BRABUS SHADOW - Page 98

Project rev.
Sheet rev.
Drawing by
Date
Modified by Description
A
B
C
D
E
F
1 2 3 4 5 6 7 8
Date of modification Sheet Loc
HL
/
Project ID Boat
Boat model
Product code
Copyright by
Sub-product code
Title
1 2 3 4 5 6 7 8
A
B
C
D
E
F
42
28 MY18
Axopar
A1: INTRODUCED DRAWING
B2: FUSES RENAMED; -M_F.10 CHANGED DD -> 88-SERIES; BATTERY CABLES AND HEATER FUSES ADDED
C3: HEATER MOVED FROM MS+ TO DIRECT+, -G1h DELIVER SEPARATELY.
TuM
VV
PN
29.6.2017
TuM
3
C
29.6.2017
22.9.2017
9.11.2017
26
2359823875
BATTERY HARNESS
2xBATT. 1xENG.
10 10
10 8
8
10 10
10 10
10 10
V4100
-C1#1
11067/456N9V02
INSULATOR FOR BATTERY TERMINAL WITH BOLT RED
11067/456N9V02
INSULATOR FOR BATTERY TERMINAL WITH BOLT RED
11068/456N9V14
INSULATOR FOR BATTERY TERMINAL WITH BOLT BLACK
11068/456N9V14
INSULATOR FOR BATTERY TERMINAL WITH BOLT BLACK
BATTERY_1+
-G1a:1
70/10
-M_S1a#1 START MS
BATTERY_1+
-M_S1a:1
70/10
-G1a#1 BATTERY 1
ENG+
-C1a:1
70/10
-M_S1c#1 START MS
ENG+
-M_S1c:1
70/8
-C1a#1 V4100
ENG-
-G1h:1
70/8
-C1d#1 V4100
BATTERY_2+
-G2a:1
95/10
-M_S3b#1 SERV MS
BATTERY_2+
-M_S3b:1
95/10
-G2a#1 BATTERY 2
INPUT-
-G1c:1
95/10
-G2b#1 BATTERY 2
INPUT-
-G2b:1
95/10
-G1c#1 BATTERY 1
INPUT-
-G1d:1
95/10
-XG1a#1 V02504
INPUT-
-XG1a:1
95/10
-G1d#1 BATTERY 1
ENG-
-C1d:1
70/10
-G1h#1 BATTERY 1
70/10
-G1h
NOTICE! CABLES WITH STICKER
EA032
STARTER STB
FOR EXAMPLE
INCLUDED
PP
NN
NN
PP
-XG.1
V02504
DELIVER -G1h SEPARATELY
INCLUDED
95 RED
1000 mm
70 RED
3500 mm
70 BLACK
4500 mm
95 BLACK
3000 mm
70 RED
4075 mm
95 BLACK
1000 mm
TAM 22 3975 mm
TAM 22 900 mm
