Bradco CONTRACTOR 408A BACKHOE - Torque Specification Chart

CYLINDER SEAL REPLACE
TORQUE SPECIFICATION CHART
Use the following torque values when tightening the nuts on the cylinder rod threads.
5613
10-16-98-2
Thread Diameter Minimum Maximum
7/8 " 150 200
* 1 " 230 325
1-1/8 " 350 480
1-1/4 " 490 670
1-3/8 " 670 900
* 1" Thread Diameter WITH 1.25" Rod Diameter...... Min. 230 ft. lbs. ..........Max. 250 ft. lbs.
POUNDS - FEET
MAINTENANCE INSTRUCTIONS
