NO REQ'D PART NO. DESCRIPTION
1 4 1043 .38" UNC X 1.00" Hex Capscrew
(Two pin retaining capscrews installed
with Locktite Grade 242)
2 2 1514 .38" Flat Washer
3 2 81807 Spacer Tube
4 2 81592 Pin
2 6616 Grease Zerk
5 1 83977 Thrust Washer 1.38" X .125"
6 2 1929 Snap Ring
7 2 6615 Bearing
8 1 83392 Mainframe
(Includes (4) #83815 Bushings - Installed
with Locktite Grade 680)
9 As Req'd 83975 Thrust Washer 1.38" X .031"
As Req'd 83976 Thrust Washer 1.38" X .090"
As Req'd 83977 Thrust Washer 1.38" X .125"
10 3 1503 .38" Lock Washer
11 2 6799 Spacer
12 2 6186 Hose Clamp
MAINFRAME ASSEMBLY
ASSEMBLY #85700
MAINFRAME
7460
6-5-98
NOTE: Use thrust washers (Item #9) to adjust mainframe / swing post to
minimum free play.
SERIAL #8408AX973 AND UP
