NO REQ'D PART NO. DESCRIPTION
1 3 1043 .38" UNC X 1.00" Hex Capscrew
(Installed with Locktite Grade 242)
2 2 1503 .38" Lock Washer
3 3 1514 .38" Flat Washer
4 3 81807 Spacer Tube
5 2 81847 Pin
6 1 85720 Swing Post (Includes (2) 81828 Bushings
Installed with Locktite Grade 680)
7 1 82534 Pin
8 As Req'd 83975 Thrust Washer 1.38" X .031"
As Req'd 83976 Thrust Washer 1.38" X .090"
As Req'd 83977 Thrust Washer 1.38" X .125"
9 3 1650 Snap Ring
10 - 81828 Bushing (Included in Swing Post)
(Installed with Locktite Grade 680)
11 1 84753 Pin
1 6616 Grease Zerk
MAINFRAME ASSEMBLY
ASSEMBLY #85700
SWING POST
7462
12-17-99-2
SERIAL #8408AX973 AND UP
(1)
NOTE:
(1) Pivot Pin #82534 is sold only in Pin Kit #86309. Kit includes one pin
#82534, two thrust washers #6623 and two snap rings #1650.
