MAINFRAME ASSEMBLY
ASSEMBLY #85700
STABILIZERS
7466
6-8-98
SERIAL #8408AX973 AND UP
NO REQ'D PART NO. DESCRIPTION
1 8 1652 Snap Ring
2 As Req'd 57693 Thrust Washer 1.25" X .078"
As Req'd 64727 Thrust Washer 1.25" X .145"
As Req'd 64728 Thrust Washer 1.25" X .031"
3 4 81846 Pin
4 2 83397 Stabilizer Cylinder Assembly
4 6616 Grease Zerk
5 2 83393 Stabilizer Arm
6 2 83257 Pin
7 2 1613 Cotter Pin .25" X 2.00"
(1)
NOTE:
(1) Pivot Pin #81846 is sold only in Pin Kit #86314. Kit includes one pin
#81846, two thrust washers #64727 and two snap rings #1652.
