NO REQ'D PART NO. DESCRIPTION
1 3 1043 .38" UNC X 1.00" Hex Capscrew
(Installed with Locktite Grade 242)
2 3 1503 .38" Lock Washer
3 3 1514 .38" Flat Washer
4 3 81807 Spacer Tube
5 2 81847 Pin
6 1 83648 Swing Post (Includes (2) 81828 Bushings
Installed with Locktite Grade 680)
7 1 82534 Pin
8 As Req'd 6623 Thrust Washer 1.38" X .031"
As Req'd 64724 Thrust Washer 1.38" X .090"
As Req'd 64725 Thrust Washer 1.38" X .125"
9 3 1650 Snap Ring
10 - 81828 Bushing (Included in Swing Post)
(Installed with Locktite Grade 680)
11 1 82321 Pin
MAINFRAME ASSEMBLY
ASSEMBLY #83371
SWING POST
6723
6-8-98-4
UP TO SERIAL #8408AX972
