MAINFRAME ASSEMBLY
ASSEMBLY #83371
SWING CYLINDER
6725
6-8-98-3
NO REQ'D PART NO. DESCRIPTION
1 2 1521 1.25" Flat Washer
2 - 62523 Self Aligning Bushing
(Included in Swing Cylinder Assembly)
3 2 81585 Spacer
4 4 68057 Thrust Washer
5 - 82441 Needle Bearing
(Included in Swing Cylinder Assembly)
6 2 81827 Swing Cylinder Assembly
(Includes (2) #82441 Needle Bearings and
(2) #62523 Bushings)
2 6616 Grease Zerk
2 30137 Tee
7 4 53031 90° Grease Zerk
8 4 82420 Pin
9 4 1047 .38" UNC X 2.00" Hex Capscrew
10 4 1514 .38" Flat Washer
11 4 81595 Spacer Tube
12 4 1837 .38" UNC Hex Lock Nut
13 - 83815 Bushing (Included in Mainframe - Installed
with Locktite Grade 680)
UP TO SERIAL #8408AX972
To Next Page
