Accessory Module Installation
-16-
Drill the Accessory Module Screw Holes
Step 7: Using a 1/8” drill bit and drill, drill the (2) screw holes that were marked in Step 5. This is shown
in Figure 7.
Position the Accessory Module
Step 8: Put the Accessory Module up against the water heater jacket and position it to the pre-drilled
holes. This is shown in Figure 8.
Figure 7
Figure 8
Marked drill
locations
Water
Heater
Drill
Water
Heater
Accessory
Module
Pre-drilled
holes
To Next Page
