Accessory Module Installation
-17-
Mounting the Accessory Module
Step 9: Using (2) of the included Philips head screws, screw the Accessory Module to the water heater
jacket, as shown in Figure 9.
Apply the Necessary Labels
Step 10: Apply both the wiring diagram and diagnostic labels. These labels should be applied to the
water heater jacket near the Accessory Module. This is shown in Figure 10.
Figure 9
Figure 10
Water Heater
jacket
Accessory
Module
Philips head
screwdriver
Apply the Wiring
Diagram and
Diagnostic labels
ccessor
Module
Water Heater
