Remote Mounting the Setback Control
-66-
Install Cover Plate
Step 21: Snap the Setback Cover Plate onto the backplate (located on the Setback Control Junction Box
Assembly). This is shown in Figure 101.
Figure 101
Remote Mounting the Setback Control is complete. Proceed to the
installation sections for the other purchased packages. Or, if
finished, proceed to the Start-up Procedure on page 67.
Backplate
Setback Control
Junction Box
Assembly
Cover Plate
