3.
5.
3
External
Trigger
Select
"Ext
Trig",
and
A
and/or
B
on
the
output
in
use.
Each
time
the
selected
slope
of
the
input
waveform
crosses
the
threshold
level
a
pulse
cycle
will
be
initiated.
3.5.4
External
Width
Select
"Ext
Trig",
and
"Square-wave"
on
the
output.
When
positive
slope
and
a
normal
positive
output
are
selected,
the
output
will
be
high
when
the
input
signal
is
above
the
thres
hold
level.
When
the
input
signal
is
a
pulse
the
output
will
have
essentially
the
same
width.
3.
5.
5
External
Gate
In
this
mode
the
"PERIOD"
oscillator
is
the
signal
source
of
the
instrument
but
it
is
able
to
oscillate
only
whilst
the
sutput
signal
is
above
the
threshold
level
(with
positive
slope
selected).
The
"PERIOD"
signal
starts
synchronously
with
the
input
signal,
but
delayed
by
a
fraction
of
a
cycle.
^
_
3.
5.
6
Countdown
Sync.
On
"External
Gate"
and
when
the
input
frequency
is
higher
than
the
PERIOD
frequency.
The
'PERIOD'
oscillator
can
be
synchronised
by
the
input
signal
up
to
a
frequency
ratio
of
100
:
1.
3.5.7
Slope
This
is
used
to
select
which
slope
of
the
input
waveform
triggers
the
unit
(initiating
pre-
pulse;
delay
A
and
on
parallel
delay,
delay
B),
or
which
part
of
the
waveform
is
used
for
the
external
width,
or
gating
signal.
On
positive
slope,
this
is
the
part
above
the
threshold
level.
3.5.8
Level
Control
Can
be
used
to
vary
the
level
on
the
input
waveform
at
which
triggering
will
occur.
It
can
also
be
used
to
vary
the
threshold
level
to
allow
triggering
from
signals
which
are
offset,
from
earth
potential.
3.
5.
9
Triggered
Light
Each
time
the
input
signal
crosses
the
threshold
level
the
lamp
flashes.
At
frequencies
above
a
few
cycles
per
second
the
lamp
appears
to
be
on
continuously.
It
is
useful
in
setting
the
trigger
level,
and
at
low
rates
to
give
a
clear
indication
of
the
instant
of
triggering.
3.
5.10
Single
Cycle
Select
"Single
Cycle",
and
A
and
/or
B
on
the
output
in
use.
Press
the
red
button
to
start
a
cycle.
3.
5.11
Manual
Step
or
Level
Select
"Single
Cycle"
and
"Square-wave"
on
the
output.
Pressing
the
red
button
produces
a
fast
step,
and
a
d.
c.
level
whilst
the
button
is
held
in.
3.
5.12
Manual
Burst
Select
this
function
by
part-pressing
one
of
the
four
black
buttons
which
is
out,
so
that
they
-
7
