1. Box Contents Check List 2
2. Hardware 3
3. Network IP Addressing 4
4. Connecting your ES Device 5
5. Installing your ES Device on Windows 6
6. Configuring your ES Device 11
6.1. Finding your COM port. 11
6.2. Advanced Configuration: Changing the IP address 11
6.3. Advanced Configuration: Changing the COM label 13
7. Default Settings 14
8. Pin outs 15
8.1. Serial DB9 Pin outs 15
8.2. Serial Terminal Block Pin outs 15
8.3. Power Terminal Block Pin outs
9. LED information 16
For more information, please refer to Product Manual on CD
Information on Product Accreditations, Safety, and correct disposal of this product can be found on the Product CD
1
Contents
Windows is a mark of Microsoft, the other marks belong to their respective owners. Brainboxes Limited. ES-QSG V2
