Brainboxes ES-246 User Manual

2. Hardware
4
1. 9 Pin D Serial Port or only on ES-357
screw terminal block connection
6. Reset button (use unfolded paperclip
to press)
2. Wall mount screw hole 7. Ethernet port connection -
10BaseT / 100BaseTX
3. Serial Port(s) LED 8. Status LED
4. Ethernet LED 9. DIN Rail kit holes
5.
ES-357/ES-246/ES-257/ES-320 - Power Input 5-30V DC, 1.8W Max / 1.0W Typical
ES-313 - Power Input 5-30V DC, 2.6W Max / 1.2W Typical
2
1
3
5 6
7
4
8
9
2
1
3
5 6
7
4
8
9
