D124.1S2-Manual_EN_Rev03
Specifications
Design snap-on track enclosure for DIN 50022 rail 35 mm,
Dimensions:
Length 100 mm, width (incl. terminal blocks) 104 mm,, height 110 mm
weight .................................................................... approx. 400 g
enclosure material ........................................................... plastics
terminals size ................................................................. 2.5 mm
2
Installation Conditions Ambient temperature in operation
Standard model: ...................................................... 0°C...+50°C
Model with suffix M (extended range): ............... -20°C...+65°C
Ambient temperature in storage .......................... -40°C....+85°C
Electrical insulation grade ......................................................... I
Voltage grade ............................................................................ I
Protection grade ......................................... ...IP20 for terminals
Power Supply Supply voltage version U1: ................ 18....40Vac/dc
version U1M : ................ 20....40Vac/dc
version U2: ................ 85..265Vac/dc
version U2M : ................ 85..265Vac/dc
Consumption 5 W resp. 5 VA
Signal input matching speed/direction sensors series A5S3..
to other sources: response level on/off >7 volts/<4 volts
input impedance 100 kohms
sensor supply approx. 12 volts/max. 60 ma
speed measurement sequence 30 msec..10 sec (programmable)
Accuracy + 0.005 % of measurement + 1 in LSD
Analog output isolated and programmable ......................................... 0/4..20ma
resolution ............................................................................ 12 bit
max. load ..................................................................... 500 ohms
linearity error ...................................................................... 0.1 %
Relay outputs 2, each SPDT
Breaking capacity voltage min 10 mv, max 250 v AC/DC
current min. 10 ua, max 2 amp AC, 1 amp DC
power rating max 100 W, 250 VA into ohmic load only.
Inductive load must be equipped with spark extinguisher
Display 5 digits LED red, with adjustable decimal point, programmable
