D124.1S2-Manual_EN_Rev03
Summary of programming steps and their initial parameters as set on delivery
comments
program- on data set on delivery *)
Step No. page parameter function (initial data)
P00 .00 6 access code request 0000
.01 6 new code figure 0000
.02 6 lock status (1= unlocked, 0=locked) 1 = unlocked
.03 6 minimum measuring time (see table) 3 = 0.4s
P01 .00 7 scaling decimals of input signal frequency 0 = none
.01 7 value of nominal input frequency (Hz) 00100
.02 7 decimals of corresponding speed 0 = none
.03 7 corresponding speed (unit as desired) 00100
.04 7 low end of speed range 00001
P02 .00 8 LSDs on zero 0 = none
.01 8 Display updating sequence 0.3 (sec)
.02 8 Direction output assigned to no-power condition (0 = forw., 1 = rev.) 1 = reverse
.03 8 minimum no of reverse pulses to release reverse alarm 05
.04 8 time period for reset of reverse pulse counter (xxx seconds) 010 sec
.05 8 forced direction at zero speed (0 = no, 1 = forw, 2 = rev) 0 = no
.06 8 reverse alarm latched until reset (0 = no, 1= yes) 0 = no
P03 .00 9 analog output high end speed value 10000
.01 9 low end speed value 00000
.02 9 zero level (0 = dead zero, 1 = live zero) 0
.03 9 1 = fix value
P04 .00 9 setpoint (SP1) in unit as programmed for display 01000
.01 9 hysteresis bandwidth (XX % of SP1) 05 (%)
.02 9 hysteresis location (0=above, 1=below, 2=symm) 1 = below SP
.03 10 alarm output assigned to "no-power" (see table) 0 = < SP
.04 10 alarm output assigned to starter phase 0 = < SP
.05 10 time elapse of starter phase (XXX sec) 000 (sec)
.06 10 function of output SP1(0 = setpoint SP1, 1 = reverse alarm SP2 0 = setpoint
P05 .00 10 not relevant 0
.01 10 not relevant 001
*) unless stated otherwise in extra sheet.
