Page 28
Exploded Views and Parts Lists
Hydraulic Cylinder Assembly - Main
1
3
2
RETRACTED
EXTENDED
STROKE
14.625
43.771
29.146
CYLINDER-14.625"/29.146 RETRACTED
ELBOW-1/4 NPT 90° 1/4 BARB
ELBOW-7/16-20 M/O-RNG/37*/.035 ORFICE
15150
26667
C1514.3-0408N
3
2
1
1
1
1
DESCRIPTIONPART NO.
ITEM QTY.
30° ±10°
