Page 9
UP
DO
W
N
3
2
8
1
9
F
O
L
D
UN
F
O
L
D
3
2
8
2
0
®
Maintenance and Lubrication
Lubrication Diagram
Handrail Pivot Pin
Bearings (4)
LO
Parallel Arm
Pivot Pin Bearings (16)
LO
Lift-Tite
™
Latches
(Tower Pivot Points - 2)
LO
Lift-Tite
™
Latch Dampening Spring
(2 springs - 4 Points) LO
Parallel Arm
Pivot Pin Bearings (16)
LO
Inner Roll Stop
Pivot Bearings (2)
LO
Outer Barrier
Pivot Bearings (2)
LO
Outer Barrier Latch
Pivot Points (2)
LO
Outer Barrier Gas Springs
(2 Springs - 4 Places)
LO
Platform Pivot Pin
Bearings (4)
LO
Outer Fold Arm
Bearings (8)
LO
Saddle
Bearing (2)
DE
Saddle Suppport
Bearings (8)
LO
Lift-Tite
™
Latch Rollers (2)
LO
Outer Barrier
Latch Roller
Bearing (2)
LO
Inner Fold Arm
Cam Followers (4)
LO
Inner Fold Arm
Roller Pin
Bearings (4)
LO
Hydraulic Cylinder
Pivot Bushings (8) LO
Inner Roll Stop
Lever Bearings (2)
and Slots (2)
LO
Outer Barrier
Switch Lever
Pivot Point
LO
See the Maintenance/Lubrication Schedule for recommended applications per number of cycles.
Outer Barrier
Activation Foot
Bearings (4)
LO
Inner/Outer Fold Arm
Contact Area (2)
LG
Specified (recommended) Available Braun
Lubricant Type Lubricant Amount Part No.
LO - Light Oil
LG - Light Grease
DE - Door-Ease
15807
15806
15805
Light Penetrating Oil
(30 Weight or equivalent)
LPS2, General Purpose
Penetrating Oil
16 oz.
Aerosol Can
Stainless Stick
Style (tube)
Door-Ease
Stick (tube)
1.68 oz.
Light Grease
(Multipurpose)
Lubriplate
14 oz.
Can
