Braun NCL917FIB-2 - Switch and Sensor Locations

Page 3
Switch and Sensor Locations
UP
DOW
N
3
2
8
1
9
FOL
D
UNFO
LD
3
2
8
2
0
®
Inboard
Outboard
Right
Left
Threshold Strip Switch
33337A (2 strips per)
*Up Microswitch
IB Occupied
Microswitch
Stow Interlock
Microswitch
IB Occupied &
Stow Interlock Assy.
32514NA
*Unfold
Microswitch
*Threshold Alarm
Microswitch
*Up & Unfold
Microswitch Assy.
975-4121A
*Threshold Alarm
& Partial Fold
Microswitch Assy.
975-4121A
IB Raised Switch
32519A
*Partial Fold
Microswitch
Outer Barrier
Occupied / Raised
Microswitch
33775A
*Note: Mirror image for
right (front) pump lifts.
Bridging
Microswitch
33689A
