BRAX Matrix X4 - Connection and Control Elements

54
15
CONNECTION AND CONTROL ELEMENTS
9
Connection remote lead
Connection ground cable
Connection BRAX Power Stabilizer (plus)
Connection battery cable
8 986
7
13101013
12 1111 12
1 2 3
1
2
3
Signal inputs
Balanced signal inputs
Level controls for input sensitivity
6
7
8
4
5
Stereo/Bridged/Mono selector
CPS - Colour Protection System
CPS - Colour Protection System
10
11
12
Connection BRAX Power Stabilizer (minus)
Loudspeaker terminals
9
Impedance selection
13
