CONNECTION AND CONTROL ELEMENTS
54
7
Connection remote lead
Connection battery cable
CPS - Colour Protection System
Connection ground cable
8
1 2 3
1
2
3
Loudspeaker terminals for channel A and B
Signal inputs channel A - D
7
8
9
4
5
Connection BRAX Power Stabilizer (plus)
6
6
Connection BRAX Power Stabilizer (minus)
9
Loudspeaker terminals for channel C and D
