BRAX Nox4 User Manual

TECHNICAL DATA
TROUBLE-SHOOTING
The BRAX NOX4 is in protection mode and the respective LED lights up yellow.
Cause: The speaker wiring is faulty (short circuit between the wires or to the chassis of the vehicle).
Remedy: Check the speaker wires or the speakers themselves for short-circuiting (p.18-20).
The BRAX NOX4 is in protection mode and the respective LED lights up red.
Cause: The amplier is overheated. It could take some time (depending on the outside temperature) until the ampli
er turns on again.
The output level of the NOX4 is to low in bridged mode
Cause: Not all RCA-inputs are connected to a signal source.
Remedy: It is necessary that all signal inputs are also connected in bridged mode to reach full output level. If
your headunit or pre-amplier delivers only a stereo signal please use Y-adaptor for the signal inputs.
22
Output power per channel at 4 Ohms........................................................................................................4 x 105 Watt RMS
Output power per channel at 2 Ohms .......................................................................................................4 x 180 Watt RMS
Output power bridged at 4 Ohms .............................................................................................................2 x 380 Watt RMS
Frequency response .......................................................................................................................................20 Hz - 20 kHz
Total harmonic distortion..........................................................................................................................................< 0,001%
TIM ..........................................................................................................................................................................< 0,009%
Signal-to-noise ratio................................................................................................................................................. > 105 dB
Damping factor .............................................................................................................................................................. > 600
Input impedance .....................................................................................................................................................10 kOhms
Input sensitivity ...............................................................................................................................................500 mV - 8,0 V
Internal fuse ...................................................................................................................................................................100 A
Dimension (H x W x D) ............................................................................................................................ 320 x 320 x 56 mm
.........................................................................................................................12,6 x 12,6 x 2,2 inch
Weight netto ............................................................................................................................................................... 8,5 kgs
