4 CPS - Colour Protection System
The LEDs show the operation status of the amplier. Yellow (11) = malfunction: short-circuit at speaker output;
Red (12) = overheated: If the amp shuts off due to overheating it will take some time (depending on the outside tempera-
ture) until it turns on again.
5-6 Connectors for a BRAX Power Stabilizer
If a BRAX Power Stabilizer is connected to this terminal peak loads in the power supply will be eliminated. Thus, the am-
plier has always enough power for its perfect performance.
Equipment and control units
7, 9 Loudspeaker terminals
To connect the speaker cables. Never connect the loudspeaker cables with the car chassis ground. It damages your
amplier. All speaker systems must be connected in-phase, it means plus to plus and minus to minus. Inverting plus and
minus will result in the loss of bass rendition. The positive terminal is marked on most speakers.
8 Signal inputs
The amplier has RCA connectors for RCA cables that can be connected with the pre-amplier outputs of a headunit or
pre-amplier. The connectors are gold-plated to ensure a better signal transmission.
Please note that all signal inputs have to be connected in bridged mode in order to reach full output level.
20
