SERIES 6A
ADVANCED SETUP GUIDE
8.3 Parameter overview
Parameter Function Parameter values Unit
1.YFCT Type of actuator Normal Inverted
Part-turn actuator turn -turn
Linear actuator WAY -WAY
Linear actuator - carrier pin on actuator spindle FWAY -FWAY
Linear actuator - external linear potentiometer
(e.g. with cylinder drives)
LWAY -LWAY
Part-turn actuator with NCS/iNCS ncSt -ncSt
Linear actuator with NCS ncSL -ncSL
Linear actuator with NCS/iNCS and lever ncSLL -ncLL
2.YAGL Rated angle of rotation of positioner shaft
1)
33° Degrees
90°
3.YWAY
2)
Range of stroke (optional setting)
3)
OFF mm
5 | 10 | 15 | 20
(Short lever 33°, range of stroke
5 to 20 mm)
25 | 30 | 35
(Short lever 90°, range of stroke
25 to 35 mm)
40 | 50 | 60 | 70 | 90 | 110 | 130
(Long lever 90°, range of stroke
40 to 130 mm)
4.INITA Initialization (automatic) NOINI | no / ###.# | Strt
5.INITM Initialization (manual) NOINI | no / ###.# | Strt
6.SCUR Current range of setpoint
0 ... 20 mA 0 mA
4 ... 20 mA 4 mA
7.SDIR Setpoint direction
Rising riSE
Falling FALL
8.SPRA Setpoint split range start 0.0 ... 100.0 %
9.SPRE Setpoint split range end 0.0 ... 100.0 %
10.TSUP Setpoint ramp up Auto / 0 ... 400 s
11.TSDO Setpoint ramp down 0 ... 400 s
Parameter assignment
8.3 Parameter overview
SIPART PS2 with 4 to 20 mA/HART
134 Operating Instructions, 10/2020, A5E00074631-AF
3.0 Setup Parameter Overview
