No. Short desig‐
nation
Meaning Representable di‐
agnostics values
Unit Properties
33 T1 Number of operating hours in temperature range 1 0 ... 4.29E9 Hours
②
34 T2 Number of operating hours in temperature range 2 0 ... 4.29E9 Hours ②
35 T3 Number of operating hours in temperature range 3 0 ... 4.29E9 Hours ②
36 T4 Number of operating hours in temperature range 4 0 ... 4.29E9 Hours ②
37 T5 Number of operating hours in temperature range 5 0 ... 4.29E9 Hours ②
38 T6 Number of operating hours in temperature range 6 0 ... 4.29E9 Hours ②
39 T7 Number of operating hours in temperature range 7 0 ... 4.29E9 Hours ②
40 T8 Number of operating hours in temperature range 8 0 ... 4.29E9 Hours ②
41 T9 Number of operating hours in temperature range 9 0 ... 4.29E9 Hours ②
42 VENT1 Number of switching cycles of pneumatic block, valve
1
0 ... 4.29E9 - ②
43 VENT2 Number of switching cycles of pneumatic block, valve
2
0 ... 4.29E9 - ②
44 VEN1R Number of switching cycles of pneumatic block, valve
1, resettable
0 ... 4.29E9 - ①
45 VEN2R Number of switching cycles of pneumatic block, valve
2, resettable
0 ... 4.29E9 - ①
46 STORE Save the current values as 'last maintenance' (press
button for 5 seconds)
- - ③
47 PRUP Prediction up 1 ... 40 - ④
48 PRDN Prediction down 1 ... 40 - ④
49 WT00 Number of operating hours in the travel range WT00 0 ... 4.29E9 Hours ①
50 WT05 Number of operating hours in the travel range WT05 0 ... 4.29E9 Hours ①
51 WT10 Number of operating hours in the travel range WT10 0 ... 4.29E9 Hours ①
52 WT30 Number of operating hours in the travel range WT30 0 ... 4.29E9 Hours ①
53 WT50 Number of operating hours in the travel range WT50 0 ... 4.29E9 Hours ①
54 WT70 Number of operating hours in the travel range WT70 0 ... 4.29E9 Hours ①
55 WT90 Number of operating hours in the travel range WT90 0 ... 4.29E9 Hours ①
56 WT95 Number of operating hours in the travel range WT95 0 ... 4.29E9 Hours ①
57 LKPUL Length of the leakage compensation pulse -256 ... 0 ... 254 ms ②
58 LKPER Period of the leakage compensation pulse 0.00 ... 600.00 s ②
59 mA Setpoint current 0.0 ... 20.0 mA ②
60 PZ Supply pressure PZ 9.999
999.99
9.999
bar
psi
MPa
③
61 P1 Actuating pressure Y1 ③
62 P2 Actuating pressure Y2 ③
63 PZMAX Maximum supply pressure PZ ①
64 N_MIN Event counter violations of lower limit PZ 0 ... 99999 - ①
65 N_MAX Event counter violations of upper limit PZ
66 N1MAX Event counter violations limit Y1
Diagnostics and troubleshooting
11.2 Diagnostics
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 10/2020, A5E00074631-AF 217
