15 of 52© 2021 BRAY INTERNATIONAL, INC. ALL RIGHTS RESERVED. BRAY.COM EN_TSM-2004-6A Advanced_Set-Up_20211012
SERIES 6A
ADVANCED SETUP GUIDE
Overview of diagnostics values
No. Short desig‐
nation
Meaning Representable di‐
agnostics values
Unit Properties
1 STRKS Number of total strokes 0 ... 4.29E9 -
2 CHDIR Number of changes in direction 0 ... 4.29E9 -
3 CNT Number of fault messages 0 ... 4.29E9 -
4 A1CNT Number of alarms 1 0 ... 4.29E9 -
5 A2CNT Number of alarms 2 0 ... 4.29E9 -
6 HOURS Number of operating hours 0 ... 4.29E9 Hours
7 HOURR Resettable operating hours counter 0 ... 4.29E9
8 WAY Determined travel 0 ... 130 mm or °
9 TUP Travel time up 0.0 / 0 ... 1000 s
10 TDOWN Travel time down 0.0 / 0 ... 1000 s
11 LEAK Leakage test - / 0.0 ... 100.0 %/minute
12 PST Monitoring of Partial Stroke Test OFF / ###.#, FdIni,
notSt, SdtSt, fdtSt,
notoL, Strt, StoP
s for ###.#
13 PRPST Time since last Partial Stroke Test ###, notSt, Sdtst,
fdtSt
Days
14 NXPST Time until next Partial Stroke Test OFF / ### Days
15 DEVI Dynamic control valve behavior 0.0 ... 100.0 %
16 ONLK Pneumatic leakage 0.0 ... 100.0 -
17 STIC Stiction (slipstick) 0.0 ... 100.0 %
18 ZERO Lower endstop 0.0 ... 100.0 %
19 OPEN Upper endstop 0.0 ... 100.0 %
20 PAVG Average value of position OFF, IdLE, rEF,
COMP
0.0 ... 100.0
%
21 P0 Potentiometer value of lower endstop (0%) 0.0 ... 100.0 %
22 P100 Potentiometer value of upper endstop (100%) 0.0 ... 100.0 %
23 IMPUP Pulse length up 6 ... 160 ms
24 IMPDN Pulse length down 6 ... 160 ms
25 PAUTP Pulse pause 2 ... 28 ... 320 ms
26 DBUP Deadband up 0.1 ... 10.0 %
27 DBDN Deadband down 0.1 ... 10.0 %
28 SSUP Slow step zone up 0.1 ... 10.0 ...
100.0
%
29 SSDN Slow step zone down 0.1 ... 10.0 ...
100.0
%
30 TEMP Current temperature -50 ... 100
-58 ... 212
°C
°F
31 TMIN Minimum temperature (min/max pointer) -50 ... 100
-58 ... 212
°C
°F
32 TMAX Maximum temperature (min/max pointer) -50 ... 100
-58 ... 212
°C
°F
Diagnostics and troubleshooting
11.2 Diagnostics
SIPART PS2 with 4 to 20 mA/HART
216 Operating Instructions, 10/2020, A5E00074631-AF
4.0 Overview of Diagnostic Values
