Parameter Function Parameter values Unit
d.
STIC Monitoring of stiction (slipstick) with the following parameters:
d1.LIMIT Limit 0.1 ... 1.0 ... 100.0 %
d2.FACT1 Factor 1 0.1 ... 2.0 ... 100.0
d3.FACT2 Factor 2 0.1 ... 5.0 ... 100.0
d4.FACT3 Factor 3 0.1 ... 10.0 ... 100.0
E.
DEBA Monitoring of deadband with the following parameters:
E1.LEVL3 *) Threshold 0.1 ... 2.0 ... 10.0 %
*) The values are monitored in the range of '0.1' to '2.9'. Values between '3.0' and '10.0' are not monitored.
F.
ZERO Monitoring of lower endstop with the following parameters:
F1.LEVL1 Threshold 1 0.1 ... 1.0 ... 10.0 %
F2.LEVL2 Threshold 2 0.1 ... 2.0 ... 10.0
F3.LEVL3 Threshold 3 0.1 ... 4.0 ... 10.0
G.
OPEN Monitoring of upper endstop with the following parameters:
G1.LEVL1 Threshold 1 0.1 ... 1.0 ... 10.0 %
G2.LEVL2 Threshold 2 0.1 ... 2.0 ... 10.0
G3.LEVL3 Threshold 3 0.1 ... 4.0 ... 10.0
H.
TMIN Monitoring of lower limit temperature with the following parameters:
H1.TUNIT Temperature unit °C °F °C / °F
H2.LEVL1 Threshold 1 -40 ... -25 ... 90 -40 ... -13 ... 194
H3.LEVL2 Threshold 2 -40 ... -30 ... 90 -40 ... -22 ... 194
H4.LEVL3 Threshold 3 -40 ... 90 -40 ... 194
J.
TMAX Monitoring of upper limit temperature with the following parameters:
J1.TUNIT Temperature unit °C / °F °F °C / °F
J2.LEVL1 Threshold 1 -40 ... 75 ... 90 -40 ... 167 ... 194
J3.LEVL2 Threshold 2 -40 ... 80 ... 90 -40 ... 176 ... 194
J4.LEVL3 Threshold 3 -40 ... 90 -40 ... 194
L.
STRK Monitoring of number of total strokes with the following parameters:
L1. LIMIT Limit 1 ... 1E6 ... 1E8
L2.FACT1 Factor 1 0.1 ... 1.0 ... 40.0
L3.FACT2 Factor 2 0.1 ... 2.0 ... 40.0
L4.FACT3 Factor 3 0.1 ... 5.0 ... 40.0
O.
DCHG Monitoring of number of changes in direction with the following parameters:
O1.LIMIT Limit 1 ... 1E6 ... 1E8
O2.FACT1 Factor 1 0.1 ... 1.0 ... 40.0
O3.FACT2 Factor 2 0.1 ... 2.0 ... 40.0
O4.FACT3 Factor 3 0.1 ... 5.0 ... 40.0
P.
PAVG Monitoring the position average value with the following parameters:
P1.TBASE Time basis of average value generation 0.5h / 8h / 5d / 60d / 2.5y
P2.STATE Status of monitoring of position average value IdLE / rEF / ###.# / Strt
P3.LEVL1 Threshold 1 0.1 ... 2.0 ... 100.0 %
P4.LEVL2 Threshold 2 0.1 ... 5.0 ... 100.0 %
P5.LEVL3 Threshold 3 0.1 ... 10.0 ... 100.0 %
Parameter assignment
8.4 Overview of diagnostic parameters
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 10/2020, A5E00074631-AF
