EN
ATTENTION!
For additional protection it is reasonable to install a
residual current device (RCD) with nominal operation
current not exceeding 30 mA, to install RCD, contact
a specialist.
EN
ESPRESSO MACHINE BR1105
The co󰀨ee maker is intended for making “espresso”
and “cappuccino” co󰀨ee.
DESCRIPTION
1. Drip tray
2. Drip tray grid
3. Tray lling pop-up indicator
4. Filter holder handle
5. Filter holder
6. Co󰀨ee lter
7. Control panel
8. Cup warming tray
9. Steam supply control knob « »
10. Cappuccinator pipe
11. Espresso machine body
12. Cappuccinator pipe tip
13. Water tank handle
14. Water tank lid
15. Removable water tank
16. Measuring spoon with ground co󰀨ee tamper
Control panel
17. Espresso machine on/o󰀨 button «
»
18. One cup button «
»
19. Steam supply on button «
»
20. Two cups button «
»
20
16
15
14
9
13
18
17
1
4
3
2
5
6
7
8
10
11
12
19
