14
Chapter 1: Hardware insertion.
Attach the
Push-On clip
from Hardware
Package #21 to
each side panel
with the system
screws provided
in the package as shown in the illustrations. The clip
will face the nished front side of the panel.
STEP 6
FIG. 1J - LEFT SIDE PANELFIG. 1I
Baseboard Notch
Front
Front
Bottom Bottom
Bed Left Side Bed Right Side
Attach the Push-On clip
from Hardware Package
#22 to each end of the
Toe Kick with the system
screws provided in the
package as shown in the
illustrations. Note: The Toe
Kick will be installed later in
assembly.
STEP 7
FIG. 1L
Toe Kick
FIG. 1K
