1 BARO button (display change between hPa,
InHg or mmHg and selection of air pressure
type)
2 WIND button (display change between mean
value and current gust)
3 RAIN button (change between daily, weekly or
monthly rainfall)
4 ALARM/SNOOZE button (snooze function)
5 MAX/MIN button (display change between max-
imum, minimum or current value)
6 HISTORY button (show measured values of the
last 24 hours)
7 INDEX button (display change between dew
point, heat index and windchill index)
8 Display
9 Wall mount 10 Wall mount adapter
11 DOWN button (Value setting downwards) 12 UP button (Value setting upwards)
13 RESET button (reset all settings) 14 RCC button (initiate RCC signal reception)
15 SENSOR button (initiate data reception from
wireless sensor)
16 °C/°F switch (display change between °C or °F)
17 HI/LO/AUTO switch (display brightness) 18 Power output cable
19 TIME SET button 20 ALARM button
21 ALERT button 22 Battery compartment cover (base unit)
23 Battery compartment (base unit) 24 DC connection socket for barrel connector
25 DC power adapter with EU power plug 26 DC barrel connector
27 Funnel (measurement of the precipitation quant-
ity)
28 Antenna
29 Circular spirit level (horizontal alignment) 30 Windmill (wind speed measurement)
31 Wind vane (wind direction measurement) 32 Radiation shield
33 Mounting rod 34 Mounting foot
35 Aperture for vertical mounting 36 Tube clamp
37 Fixing screw 38 Fixing screw with nut
39 Aperture for horizontal mounting 40 Battery compartment cover (wireless sensor)
41 Fixing screw (battery compartment cover) 42 RESET button (reset all settings)
43 Aperture for the mounting rod in sensor head 44 Function light (wireless sensor)
45 Battery compartment (wireless sensor) 46 Sealing ring
Delivery content
Base unit (A), power adapter (B), wireless sensor (C), mounting rod with 2 screws and 2 nuts (D), tube
clamp with 4 screws and 4 nuts (E), mounting foot (F)
Required batteries (not included):
Station: 3 pcs. Micro batteries (1.5V, type AAA); sensor: 3 pcs. Mignon batteries (1.5V, type AA)
Also required (not included):
Small cross screwdriver, 4 wood screws
