Breville Oracle Touch - Assembly; Before First Use

7
Components
A. Integrated conical burr grinder
with removable ½lb bean hopper
B. Top-fill 84 fl.oz (2.5L) removable water
tank with integrated water filter and backlit
level indicator
C. Grind size dial
adjust grind size to suit your coffee beans
D. Touch screen control panel
displays current settings and provides
touch interface
E. Grind outlet
with auto grind, dose & tamp function
F. Heated 58mm group head with
embedded element
G. 58mm full stainless steel portafilter
H. Drop down swivel foot
lifts the machine upwards for
easy maneuverability
I. Heated cup warming tray
J. Cool touch steam wand
with integrated temperature sensor for
automatic frothing
K. Dedicated hot water outlet
delivers hot water for Americano
and pre-heating cups
L. Descale access point
M. Tool storage tray
houses accessories when not in use
N. Removable drip tray
with Empty Me! indicator
G
H
E
D
F
B
C
A
J
L
N
M
K
I
