Coupling To The Tow Vehicle
Bri-Mar 84
GGooseneck Height Adjustment – Figure 4-13
Fully
Retracted
Maximum
Extension 8”
Loosen the jam nut and bolt (1). Remove locking pin (2). Extend or
retract the receiver as needed. The maximum the receiver can be
extended is 8 inches. See figure 4-14.
Reinstall locking pin (2). Tighten bolt (1) to 150-170 lb. ft. of torque.
Tighten jam nut to 80-90 lb. ft. of torque prevent bolt from loosening.
Improper gooseneck height adjustment can result in overloaded tires,
blowout and loss of control, leading to death or serious injury.
Adjust the gooseneck receiver so that the trailer runs level.
(1)
(2)
(2)
Trailers
