BS-7100-IG (7523) V1.0 ENG
typ. 0.5A at 12Vdc / typ. 0.28A at 24Vdc / max. <0.6A
3A, automotive (regular size) blade fuse type, located on red
power supply cable
System supplies: positive & negative, activation input, and
trigger output6 single cables exiting at the back of the
connector on the end of the display cable
Rating 0Vdc to 32Vdc
System active above 7Vdc, inactive below 7Vdc
Active State: switched to ground up to 0.5A
Inactive State: High impedance (> 1M Ohm)
ISO 16750 (over and reverse voltage protection)
