ENGINE SPECIFICATIONS
MODEL 090600
ENGINE SPECIFICATIONS
Alternator Air Gap .006 - .014 in. (.15 - .33 mm)
Armature Air Gap .006 - .014 in. (.15 - .33 mm)
Crankshaft End Play .002 - .038 in. (.05 - .97 mm)
Spark Plug Gap .020 in. (.51 mm)
Valve Clearance – Intake .004 - .006 in. (.10 - .15 mm)
Valve Clearance – Exhaust .014 - .016 in. (.36 - .41 mm)
FASTENER TORQUE SPECIFICATIONS TORQUE
Air Cleaner Base 45 lb-in. (5 Nm)
Air Cleaner Cover 12 lb-in. (1 Nm)
Alternator 55 lb-in. (6 Nm)
Armature 85 lb-in. (10 Nm)
Blower Housing 85 lb-in. (10 Nm)
Breather Cover 55 lb-in. (6 Nm)
Breather Reed 45 lb-in. (5 Nm)
Bowl Nut 90 lb-in. (10 Nm)
Carburetor to Cylinder Head 85 lb-in. (10 Nm)
Casing Clamp 20 lb-in. (2 Nm)
Connecting Rod 95 lb-in. (11 Nm)
Control Bracket 95 lb-in. (11 Nm)
Control Panel Trim 40 lb-in. (5 Nm)
Crankcase Sump 110 lb-in. (12 Nm)
Cylinder Head 210 lb-in. (24 Nm)
Flywheel Brake Assembly 45 lb-in. (5 Nm)
Flywheel Guard 45 lb-in. (5 Nm)
Flywheel Nut 60 lb-ft. (81 Nm)
Fuel Tank 85 lb-in. (10 Nm)
Governor Lever Nut 30 lb-in. (3 Nm)
Muffler 85 lb-in. (10 Nm)
Muffler Guard 45 lb-in. (5 Nm)
Muffler Deflector 15 lb-in. (2 Nm)
Oil Drain Plug 145 lb-in. (16 Nm)
Rewind Assembly/Static Guard 30 lb-in (3 Nm)
Spark Plug 180 lb-in. (20 Nm)
Starter Motor Bracket 85 lb-in. (10 Nm)
Starter Drive Cover 20 lb-in. (2 Nm)
Valve Cover 55 lb-in. (6 Nm)
Valve Clearance Nut 20 lb-in. (2 Nm)
