Briggs & Stratton Power Products Home Generator System
Owners Manual
ENCLOSURE PARTS LIST
Item Part # Qty. Description
1 186564GS 1 PAD, Foundation Base w/ Holes
2 H185972GS 1 BASE, Mounting
3 186061GS 8 BUSHING, Stem
4 H185971GS 1 DOOR,Alternator Side
5 186049GS 3 HANDLE, Door, Recessed Pull
6 189792GS 5 MACHINE SCREW, Phillips Pan
Head
7 H185962GS 1 CORNER,Alt.Air Inlet Right
8 B4300GS 40 SWAG BOLT
9 H185968GS 1 BAFFLE, Horizontal,Alt. Side
10 H185961GS 1 CORNER,Alt.Air Inlet, Left
11 H185965GS 1 PANEL, Muffler Air Out
12 186582GS 1 BUSHING, Snap
13 H185966GS 1 BULKHEAD,Alternator Side
14 B5053GS 1 KEY, Lock
15 186172GS 2 ASSEMBLY, Lock/Doors
16 H187232GS 2 DOOR, with Insulation
17 H186046GS 2 RAIL, Support Upper Front/Back
18 H187234GS 1 ROOF, with Insulation
19 H185963GS 1 CORNER, Engine Air Inlet Right
20 H186047GS 1 RAIL, Support Upper Engine Side
21 H185969GS 1 DOOR, Engine Air Inlet
22 H185964GS 1 CORNER, Engine, Left Side
23 H187235GS 1 BAFFLE, with Insulation
24 74908GS 12 TAPTITE
25 B4986GS 1 DECAL, Ground
Item Part # Qty. Description
26 186173GS 2 BUSHING, Snap
27 H185967GS 1 BULKHEAD, Engine Side
28 186065GS 1 SEAL, Foam Engine Air Inlet
29 B4889GS 1 SEAL, Foam Alternator Air Inlet
30 H186760GS 1 COVER, Control Panel
31 29745GS 4 CAPSCREW, Hex Head
32 185976GS 6 PLUG, Hole
33 22131GS 4 FLATWASHER
34 22237GS 4 LOCKWASHER
35 22241GS 4 NUT
36 187060GS 1 CLAMP, Nylon
37 186202GS 6 CLAMP, Nylon
38 186277GS 1 WIRE HARNESS, Engine
39 B5082GS 1 DECAL, Danger High Voltage
40 22097GS 4 LOCKWASHER
41 49813GS 4 NUT
42 186790AGS 1 WIRE, Ground,To Control Panel
43 186345GS 1 LUG, Ground
44 186640GS 1 DECAL, LP/Natural Gas
45 186640GS 1 DECAL,Terminal Strip
46 28739AGS 1 TIE WRAP, Black
47 26850GS 1 WASHER, Ext. Shakeproof
48 186174GS 2 CAMBAR, Lock
Part Not Illustrated
187008GS 1 KIT, Door Seal
