Briggs & Stratton InfoHub 6520 - Page 5

5
A • L1 IN
B • L2/N IN
C • 230VAC N
D • Ground
E • L1 OUT
F • L2/N OUT
G • Network Configuration Button (Join)
H • Power LED
J • Relay LED
K • Fault LED
L • Network LED
A • 24VAC Power Input
B • Network Configuration Button (Join)
C • Load #2 Output
D • Load #1 Output
E • Fault LED
F • Network LED
G • Power LED
H • Output 2 LED
J • Output 1 LED
G
B A EF
C
L2/N OUT L1 OUTL2/N IN L1 IN 230VAC N 230VAC N
D
J K L
H
Figure 2
A
C
D
B
E
G
H
J
F
Figure 3
