7 Technical data
Specification Value
Rated voltage 220–240 V, 50 Hz
Output 120 W
Refrigerant R600a
Tank volume 1.5 l
Ice tray volume 1.5 l
Cord length 1.2 m
Dimensions (WxDxH) 228x320x297 mm
Weight 7.6 kg
8 Troubleshooting
Problem Cause Action
The compressor works abnormally with a
buzzing noise.
The voltage is out of specification. Stop the product and make sure that
the power outlet voltage is inside
specification.
The ADD WATER indicator light is on. The tank is empty. Fill the tank with water.
The pump is full of air. Push the power button to restart the
product.
The ICE FULL indicator light is on. The ice tray is full of ice. Scoop out the finished ice with the
ice scoop.
The ICE FULL indicator light does not
come on when the ice tray is full.
Ice full sensor is damaged. Contact an authorized service
center.
The sensor is interfered by sunlight. Move the product away from
sunlight.
The indicator lights are o. The fuse is blown. Replace the fuse.
There is no power. Turn the product on.
The ice is very large and pieces stick
together.
The ice from previous cycles is left in the
water tray.
Remove the ice from the water tray.
The product operates but makes no ice. The compressor has no refrigerant. Contact an authorized service
center.
The compressor is damaged.
The fan motor is damaged.
All of the indicator lights flash
simultaneously.
The water tray is blocked by ice. Disconnect the power and remove
the ice.
The motor is stuck or damaged. Contact an authorized service
center.
The micro switch is damaged.
The product operates but the water
becomes warm.
The solenoid is broken. Contact an authorized service
center.
