VI. List of Six-Way Valve Components
Item Description
1 Lever
2 Fulcrum
3 Board
4 Screw with a nut, cover
5
Cover set-up
6 O-ring cover
7 Board
8 Spring
9 O-ring of the revolving wheel
10 Revolving wheel
11 Filtration bag - spider
12 Body-diffuser
13 O-ring of the end piece
14 Adapting pipe of the end piece
15 O-ring of the end piece
16 End piece adapter
17 End piece nut
18 O-ring of the central pipe
19 O-ring of the fi lter
20 Screw with a nut, clamp
21 Flange clamp
22 Overfl ow, diffuser
23 Nut, plug
24 Plug with the O-ring
25 Waste aperture
26 Connector
