6
Model with horizontal discharge
Model with vertical discharge
Warning:
• Do not put your hand or any object into the air outlet or ventilator, as this could damage the device and
cause an injury.
• In the event of any abnormalities, switch off the device immediately and contact an expert technician.
• If needed, you should place barriers next to the device to keep children away from the running heat
pump.
air
inlet
air
inlet
air
outlet
min.
1000 mm
min.
1000 mm
min. 1000 mm from above
min. 1000 mm
min. 2000 mm
air
inlet
air
inlet
air
inlet
air outlet
min. 1000 mm from above
min.
1000 mm
min.
1000 mm
more than 1000 mm
Requirements for free space around the horizontal heat pump
Requirements for free space around the vertical heat pump
min. 2000 mm from above
EN
