INVERTER
SWIMMING POOL HEAT PUMP
USER MANUAL
Illustrative photo
i
Read the instructions
EN
VERZE 8. 6. 2017 / REVIZE: 3. 11. 2017

Table of Contents

Questions and Answers

  • F
    Francisco CalhounAug 14, 2025
    Why does my Brilix XHPFD 80 E Heat Pump show a high pressure error?
    • G
      Gregory RayAug 14, 2025
      A high pressure error in your Brilix Heat Pump can occur due to several reasons: * Too much refrigerant: In this case, drain the excess refrigerant. * High water or environment temperature: Clean the air heat exchanger. * Operating frequency too high: Check and reconnect the electrical cables from the high pressure switch and replace the high pressure switch. Additionally, ensure there are no gas leaks (contact a specialized company to add refrigerant if needed), clean the air heat exchanger, replace the filter, and check/reconnect the electrical cables from the low pressure switch, potentially replacing the low pressure switch.
  • D
    Drew KleinAug 17, 2025
    What to do if my Brilix XHPFD 80 E Heat Pump has low pressure error?
    • D
      Daniel ThompsonAug 17, 2025
      If your Brilix Heat Pump displays a low pressure error, it could be due to: 1. Not enough refrigerant: Check for gas leaks and have a specialized company add refrigerant. 2. Insufficient flow: Clean the air heat exchanger. 3. Dirty filter: Replace the filter. 4. EEV failure. 5. Fan motor fault. 6. Low pressure switch failure: Check and reconnect the electrical cables from the low pressure switch, and if necessary, replace the low pressure switch.
  • C
    Craig PalmerAug 21, 2025
    What to do if my Brilix XHPFD 80 E Heat Pump has impaired water flow?
    • D
      Dorothy HarrisAug 21, 2025
      If you are experiencing impaired water flow with your Brilix Heat Pump, it could be caused by: weak water flow, flow in the wrong direction, or flow switch failure. To resolve this: 1. Ensure the water flow is sufficient. 2. Make sure the water flow switch is connected correctly. 3. Check the wiring to the water flow switch. 4. Replace with a new water flow switch if necessary.
  • S
    Sean MyersAug 25, 2025
    How to fix sensor error inlet water temperature in Brilix Heat Pump?
    • M
      mckeejosephAug 25, 2025
      If your Brilix Heat Pump displays a sensor error for the inlet water temperature, it indicates that the sensor is either open or short circuited. To resolve this, check or replace the sensor.
  • L
    Leslie RodriguezAug 28, 2025
    How to fix sensor error outlet water temperature in Brilix Heat Pump?
    • S
      Sarah TaylorAug 28, 2025
      If your Brilix Heat Pump displays a sensor error for the outlet water temperature, it means the sensor is either open or short circuited. You should check or replace the sensor.
  • J
    John MillerAug 31, 2025
    How to fix sensor error heating condenser in Brilix Heat Pump?
    • R
      Rodney HillAug 31, 2025
      If your Brilix Heat Pump shows a sensor error for the heating condenser, the sensor is likely open or short circuited. The suggested solution is to check or replace the sensor.
  • L
    Lori OlsonSep 3, 2025
    How to fix sensor error gas return in Brilix XHPFD 80 E?
    • T
      Timothy VillaSep 3, 2025
      If your Brilix Heat Pump displays a sensor error related to gas return, it indicates that the sensor is either open or short-circuited. The solution is to check or replace the sensor.
  • J
    Joseph CruzSep 7, 2025
    How to fix sensor error ambient temperature in Brilix XHPFD 80 E?
    • E
      Erik MedinaSep 7, 2025
      If your Brilix Heat Pump is showing a sensor error for the ambient temperature, this indicates the sensor is open or short circuited. You should check or replace the sensor.
  • L
    Lauren MataSep 10, 2025
    How to fix sensor error gas at the condenser output in Brilix XHPFD 80 E Heat Pump?
    • L
      lawrencegarciaSep 10, 2025
      If your Brilix Heat Pump displays a sensor error for gas at the condenser output, it means the sensor is either open or short circuited. You should check or replace the sensor.

Summary

Safety and Operational Notes

ATTENTION: Manual Information

This section highlights the manual's comprehensive coverage for heat pump use and installation.

WARNING: Winter Drainage Procedure

Essential safety warning regarding emptying the heat pump to prevent freezing damage and warranty loss.

WARNING: Electrical Safety Precautions

Crucial safety advice to cut power before accessing the heat pump's internal high-voltage components.

WARNING: Display Controller Protection

Guidance on protecting the display controller from humidity damage by keeping it dry or covered.

Specification

Dimension

Installation

Installation Factors

Key factors for optimal performance: good ventilation, stable power supply, and a recycled water system.

Installation Diagrams and Notes

Illustrations and important notes on system installation, including bypass and chemical placement.

Adjusting the Bypass

Initial Operation

Water Flow Switch

Explanation of the flow switch function for protecting the heat pump unit with adequate water flow.

Time Delay

Details on the built-in 3-minute start-up delay to protect circuitry and avoid contact wear.

Condensation

Information on condensation formation on evaporator fins due to cooling, often mistaken for leaks.

Pressure Gauge Display (R410 A)

Guide to interpreting the refrigerant gas pressure gauge (R410A) under different operating conditions.

Controller Operation

Controller Buttons and Symbols

Overview of controller buttons, symbols, and their functions for operating the heat pump unit.

Parameter Settings

Instructions for checking and adjusting user parameters (d0-d11, P1-P7) on the controller.

Operating Modes and Reset

Explanation of operating modes (Powerful, Smart, Silent) and the system reset function.

Operation Logic

Heating Operation Logic

Details the operational logic for the heat pump during heating cycles based on working status and temperature.

Cooling Operation Logic

Details the operational logic for the heat pump during cooling cycles based on working status and temperature.

Malfunction and Trouble Shooting

Error Code Display

Table of error codes displayed on the LED wire controller, their reasons, and troubleshooting solutions.

Other Malfunctions

Troubleshooting guide for other malfunctions, including heat pump not running and water stains.

Electrical Wiring

Electrical Connection and Disconnect

Guidance on electrical connection, earthing, bonding, and proper unit disconnection for servicing.

Maintenance

Exploded View

Brilix XHPFD 80 E Specifications
